QH11D Series Tyuecut-Menchanical Shearing Machine

Short Description:

Mechanical Shears: Definition and Core Functions Mechanical shears are specialized tools or machines designed for cutting various materials through mechanical force, typically featuring sharp blades and a mechanism to apply pressure for precise or high-volume cutting. They are widely used in industries such as metalworking, gardening, and manufacturing, with applications ranging from trimming h

Send email to us Download as PDF

Product Details

Product Tags

Functions and Characteristics：

This Machine Is Different From The Traditional Driving Method Of Mechanical Shearers, Its One The Most Advanced Mini Mechanical Shear And Enjoys Good Reputation Both At Home And Abroad. A Brake Motors Driving Through A Shaft Mounted Speed Reduction Unit And Controlled By As Selector Foot Switch For Single Or Continuous Strokes And Featured Instantaneous Combination. The Smaller Cutting Angle And Inclined Shearing Direction Reduces Bowing And Twist To A Minimum. Blade Clearance Is Easily Set By A Manually Operated" Quickest" Device, Its An Ideal Truecut Machining Equipment Of Sheet Metal And Nonferrous Sheet Metal.

Main Technical Data:

Speci fication/Para-meter	Shearing Thickness(mm)	Shearing Width(mm)	Shearing Angle	Number of Stroke(min-1)	Back gauge Range (mm)	Height of the Table(mm)	Motor Power(kw)	Overall Dimen-sions (mm)	Net Weight (kg)
3.5×1250	3.5	1250	1°30'	47	0-650	800	5.5	1860×2210×1180	1450
3.2×2000	3.2	2000	1°45'	47	0-650	800	7.5	2624×2210×1180	1800
2.5×2500	2.5	2500	1°	47	0-650	800	7.5	3124×2210×1180	2000
3.2×2500	3.2	2500	1°18'	47	0-650	800	7.5	3124×2210×1180	2100
